Features

• Color TFT display
• Synchronized Operation
• Event trend Storage
• 24 Hours Trend
• ECG acquisition through paddles & patient cable
• Easy Energy selection up to 270 Joules
• Less than 8 sec to charge 270 Joules

• Display

  - Type : Color TFT display

  - Size : 7” Diagonally

  - Resolution : 800 x 480 Pixels

• Measuring Parameters

  - Channel : 2 Channel

  - Electrode : 3 / 5 Leads

  - ECG Acquisition : Patient Cable and Paddles

  - Display : 2 Waveforms with HR and Joules selected

  - Lead : Lead I, II, III, aVR, aVL, aVF, V

  - Gain Selection : 5 /10 /15 /20 mm/mvs

  - Sweep Speed : 12.5, 25 or 50 mm/sec

  - Heart rate range : 30-240 bpm

  - Heart Rate Accuracy : + 2 bpm

  - Frequency Response : 0.05 to 40 Hz

  - CMRR : >100 dB

  - Input Impedance : >100 M Ohms

• Defibrillator

  - Maximum charging time to 270 joules : 8 seconds

  - Energy Selection :
  2,3,5,7,10,20,30,40,50,70,100,150,200,250,270

  - Synchronous operation : Yes

• Recorder

  - Type : High Resolution thermal array recorder

  - Printing Speed : 25 mm/sec

  - Printer Paper Size : 57 mm x 20 Mtr

  - Details on print : HR,ECG w/f along with energy delivery, Date, Time , Patient Details (ID, name, age, sex), Joules selected, Sweep speed and Gain

• Electrical

  - Power Input : AC 230 V, 50 Hz

  - Battery Rating : 14.8 V / 4400 mAh, Li-Polymer

  - Charging Time : 8 Hours

  - Operating Time : 40 + shocks (270 joules) or more than 3 Hours monitoring without printing

• General

  - Weight : 5.4 Kg

  - Dimensions : 403 (L) X 152 (H) X 324 (W) mm

  - Working temperature and humidity : 0-40 deg. cel. & up to 90% non condensing
